Cisco IP Phone 7945G VoIP Phone

Product Description for Cisco IP Phone 7945G VoIP Phone

• Brand: Cisco
• Model: IP Phone 7945G
• Model Number: CP-7945G
• Phone Type: Business-class VoIP desktop phone
• Display: 5-inch (12.5 cm) back-lit colour graphical TFT, 320 × 240 pixels
• Programmable line/feature keys: 2 line/feature buttons
• Soft keys: 4 context-sensitive soft keys
• Navigation: 4-way navigation pad plus Select key
• Speakerphone: Full-duplex speakerphone with acoustic echo cancellation
• Headset port: Dedicated headset connection
• Ethernet switch: Two-port integrated Gigabit Ethernet switch (10/100/1000 Base-T)
• Power options: IEEE 802.3af Power over Ethernet (Class 3) or optional local AC adapter or PoE injector
• Supported protocols: SCCP and SIP signalling
• Voice codecs supported: G.711 (A-law & µ-law), G.729a, G.729ab, G.722 (wideband), iLBC
• Network features: IEEE 802.1Q VLAN tagging, IEEE 802.1p priority, DHCP/static IP address assignment, TFTP support
• Security features: 128-bit AES encryption, IEEE 802.1X authentication, media and signalling encryption (depending on configuration)
• Lines supported: 2 lines (or speed-dials/features configured as lines)
• Display colour depth: 16-bit (65,000 colours)
• Body material: ABS plastic in textured dark grey with silver bezel
• Dimensions (H × W × D): 20.32 × 26.67 × 15.24 cm (8.2 × 10.5 × 6 in)
• Weight: Approximately 1.6 kg (3.5 lb)
• Operating temperature: 0 °C to 40 °C (32 °F to 104 °F)
• Operating relative humidity: 10% to 95% non-condensing
• Placement: Table-top or wall-mountable
• Additional features: Back-lit colour display, built-in XML application support, voicemail key, directories, services button
