NEC NP-PA903X + NP13ZL Lens Professional Installation Projector

Write a review
Click below on "Inquiry" button for discount prices.
EP000036
Send us inquiry

Highlights of NEC NP-PA903X + NP13ZL Lens Professional Installation Projector

  • 4K Ready
  • Powered Lenses
  • Manual Keystone Correction
  • 3D Stereo
  • Geometric Correction
  • 10,000 hour Filter Life
  • Quick power on
  • ECO Mode Technology
  • DiCom Simulation
  • Edge Blending
  • Stacking
  • Virtual Remote
  • DisplayNote
  • NaViSet Administrator 2
  • Quick power-off
  • Picture-in-Picture
  • Advanced AccuBlend
  • AutoSense

Product description for NEC NP-PA903X + NP13ZL Lens Professional Installation Projector

NEC’s PA903X is a 9000 lumen advanced professional installation model that appeases higher education and corporate users. With its multitude of digital inputs, connection to any computer or high definition device is possible. Enjoy design and installation flexibility with a complete line of optional powered lenses (lens shift, focus and zoom), tilt-free and portrait installation capabilities along with built-in edge bledning and stacking. The HDBaseT input and seperate HDBase T loop out provide single connections for uncompressed full HD digital video, audio, ethernet power and various control signals.


Product Specifications for NEC NP-PA903X + NP13ZL Lens Professional Installation Projector

Display

Aspect Ratio4×3Native ResolutionXGA 1024 x 768
Maximum Resolution4K 4096 x 2160Contrast Ratio (typical)10,000:1 with auto iris

Synchronization Range

Horizontal (Analog/Digital)Analog: 15-100kHz, Digital: 15-153kHzVerticalAnalog: 48-120Hz, Digital: 24-120Hz

Signal Compatibility/Connectivity

Supported Video StandardsNTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAMSD/HD Video Signal Compatibility480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K
PC Signal CompatibilityVGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA, WQXGAMacintosh Signal CompatibilityYes
Sync CompatibilitySeparate Sync / Composite Sync / Sync on GExternal ControlRS-232, IR, HDBaseT, DDC/CI, USB
Input Terminals
RGB1(analog): VGA 15-pin D-sub
RGB2(digital): HDMI w/HDCP (V2.2)
RGB3(digital): HDMI w/HDCP (V2.2)
RGB4(digital): DisplayPort w/HDCP (V1.4)
RGB5(digital): HDBaseT w/HDCP (V2.2)
Audio 1: Stereo Mini Jack 		Output Terminals
Audioout: Stereo Mini
Jack Monitor Out: HDBaseT

Power Consumption (typical)

On566W / 390W / 0.7W / 0.3WInput Current6.2-3.1A
Power Requirements100-240V AC, 50/60 Hz

Physical Specifications

Dimensions (WxHxD)
Product: 19.8 x 16.2 x 6.6 in. / 503 x 411 x 168mm 		Weight
Net Weight: 22.5 lbs. / 10.2 kg

Environmental Conditions

Operating Temperature41-104°F / 5-40°CStorage-14-122°F / -10-50°C

Additional Features

  • 4K Ready
  • Powered Lenses
  • Manual Keystone Correction
  • 3D Stereo
  • Geometric Correction
  • 10,000 hour Filter Life
  • Quick power on
  • ECO Mode Technology
  • DiCom Simulation
  • Edge Blending
  • Stacking
  • Virtual Remote
  • DisplayNote
  • NaViSet Administrator 2
  • Quick power-off
  • Picture-in-Picture
  • Advanced AccuBlend
  • AutoSense

Optical

Mechanical

Display Technology0.76″ LCD w/ MLA
Lamp Type420W AC
Screen Size (diagonal)40 to 500 in. / 1.02 to 12.7m
Projector Angle10.3 to 10.8° tele / 13.7 to 14.5° wide
Keystone Correction+/- 40° horizontal, +/- 30° vertical
Light Output(Lumens)9000normal
Lamp Life (up to)3000 hours normal / 5000 hours eco
Projection Distance2.5 to 68.5 ft. / 0.74 to 20.9m
LensZoom: Variable Focus: Power F number, fnumber: Variable
Installation OrientationFloor/Front, Floor/Rear, Ceiling/Front, Ceiling/RearFan Noise39 dB normal / 33 dB eco
RegulationsUSA UL60950-1: 2nd edition, FCC Part15 Subpart B(ANSI C63.4.2014), CAN/CSA C22.2 No.60950-1-07,2nd Edition,2014, ICES-003 Issue6(ANSI C63.4:2014)Optional LensesNP11FL, NP12ZL, NP13ZL, NP14ZL, NP30ZL, NP40ZL, NP41ZL, NP42ZL

Light Output

9000normal

Fan Noise

39 dB normal / 33 dB eco
